DLD-9 Dual Read High Temperature Sensor

High-Temperature Probe Sensor (K-Type / T-Type Compatible)

Designed for hot storage and high-temperature monitoring, this probe sensor makes it easy to automate the recording of hot holding areas, ovens, and similar equipment. Fully integrated with the ComplianceTrackr app, it also works with the app’s Time Temperature Log (TTL) feature (limited to the first connected sensor).

✅ Dual probe support – connect up to two probes simultaneously.
✅ Flexible probe type – supports both K-Type and T-Type probes.
✅ Remote configuration – if you switch probe types, email support@sm8a.com.au and we’ll update your sensor settings remotely.

⚠️ Important Note: The sensor box must not be placed inside ovens or hot boxes. Only the probe end is heat-resistant and suitable for high-temperature environments.

Key Benefits

• Automates high-temperature logging for HACCP compliance.

• Long battery life (up to 3 years with standard use).

• Strong LoRa connectivity with up to 2 km transmission range.

• Reliable accuracy for both low and high-temperature environments.

Technical Specifications

• Battery: Built-in 4000 mAh / 3.6 V

• Measure Media: Ambient air

• Thermocouple Measuring Range:

  • K-Type: –200 °C to +1370 °C

  • T-Type: –200 °C to +400 °C

• Accuracy:

  • Above 100 °C: ±1 °C

  • Below 100 °C: ±2 °C

• Operating Environment: –30 °C to +60 °C, 0–85% RH (non-condensing)

• RF Frequency: 915 MHz

• Modulation: LoRa

• Max Transmission Range (open area): 2 km

• Transmit Power: 20 dBm (adjustable)

• Transmit Interval: 1–1440 minutes (user definable)

• Standby Current: < 5 µA

• Ingress Protection: IP54

• Battery Life:

  • Up to 3 years (15-minute intervals)

  • Up to 2 years (in freezer use)

• Dimensions: 106 × 57 × 33 mm

• Weight: 135 g
